Height | ? Verifier height: 2.13 inches (54.10 mm) ? Total height including handle: 4 inches (101.6 mm) |
---|
Length | 3.94 inches (100.08 mm) |
---|
Width | 6.56 inches (166.62 mm) |
---|
Weight | 1.3 pounds (.589 kg) |
---|
Scanner | ? 400 DPI ? Floating Sensor Head |
---|
Overall Scanning Width | ? 5.4 inches (137.16 mm) in picket fence format ? Up to 8.0 inches (203.2 mm) in ladder format |
---|
Minimum X-Dimension | ? 1D (Narrow Bar Width): 8.8 mils (.0088”) (.223 mm) ? 2D (Cell Size): 12.5 mils (.0125”) (.317 mm) |
---|
Verification | 1D and 2D codes that comply with ISO/IEC standards and GS1 General Speci?fications |
---|
Light Source | Red Light, 660 nm |
---|
Inputs / Outputs | USB 2.0 Port |
---|
Operating Temperature | 10o C (50o F) to 30o C (86o F) |
---|
Storage Temperature | 0o C (32o F) to 40o C (104o F) |
---|
Relative Humidity | 20% to 70% (non-condensing) |
---|
Calibration | EAN/UPC Calibrated Conformance Test Card (part # CAL002) |
---|
Minimum PC Requirements | ? Windows? XP Professional or Windows? 7 (Windows? Vista is not supported) ? Intel? Core? 2 Duo Processor (or equivalent) ? 2 GB RAM ? 800 x 600 Resolution ? One available USB 2.0 port |
---|
